High-Tech Pumps of Hastelloy® Completely corrosion-resistant – detail by detail

The versatility of this product group will certainly increase your heart rate: Every component of the pump is designed to fulfill the highest requirements.

Hastelloy® pumps from SCHERZINGER
– no request goes unfulfilled:

Hastelloy-Pumpen von Scherzinger sind korrosionsbeständig.

Corrosion-resistant

All components of the pump are highly corrosion-resistant.

Breites Einsatzspektrum von Scherzinger Hastelloy-Pumpen zur Förderung verschiedener Medien.

Application range

All pumps in this category can convey oxidizing, reducing and chlorine-containing mediums.

Maximale Sicherheit bei der Entwicklung und Fertigung von Hastelloy-Pumpen.

Reliability

All process steps of our development and production are designed for maximum operation safety – for maximum safety in your application.

Hermetically sealed Hastelloy® pumps

Size Geometric conveyed volume
[ ml / u ]		 Maximum rotation speed
[ 1 / min ]		 Maximum volume flow
[ l / min ]		 Maximum differential pressure
[ bar ]		 Maximum input pressure
[ bar ]		 Viscosity
[ mPas ]		 Temperature range
[ °C ]		 Download
3040

0.45
0.7
1.1
*

 4000 1.8
2.8
4.4		 7


30		 60


90		 0.5 ... 3000


0.5 ... 20,000		 -20 ... 70


-40 … 200		 CAD data
CAD data
CAD data

Data sheet
4040 2.8
4.5
7.1
*		 3500

3000		 9.8
15
21		 7


30		 60


90		 0.5 ... 5000


0.5 ... 20,000		 -20 ... 70


-40 … 200		 CAD data
CAD data
CAD data

Data sheet
5040

13
21
35
*

3000
2800
2600

 39
58
91		 7


30		 60


90		 0.5 ... 6000


0.5 ... 20,000		 -20 ... 70


-40 ... 200		 CAD data
CAD data
CAD data

Data sheet


* maximum possible application area with application-specific and construction adjustments


Possible material combinations

Casings & shafts Gear wheels Slide bearings Seals
Hastelloy® C4 PEEK mod.
PEEK HT
PTFE mod.
PPS mod.		 PEEK mod.
PTFE mod.
PPS mod.
SSiC / Cr2O3
SSiC / Al2O3		 PTFE
FKM
FFKM
EPDM



Produced for applications such as:

Chemical dosing

Charging station cooling

Gas turbines
