Titanium Gear Pumps Power products made of highly corrosion-resistant active substance combinations
Anyone looking for a pump that fulfills the highest requirements for corrosion-resistance can be certain with SCHERZINGER: The series 2050–5050 are especially suitable for application areas that place heavy demands on the material for individual components – for example, the conveyance of aggressive acids.
Corrosion-resistance
All components of the pumps are highly corrosion-resistant.
Combination fortitude
All pumps in this category can convey chlorine-containing and highly oxidizing acids.
Reliability
All process steps of our development and production are designed for maximum operation safety – for maximum safety in your acid application.
| Size | Geometric conveyed volume [ ml / u ] | Maximum rotation speed [ 1 / min ] | Maximum volum flow [ l / min ] | Maximum differential pressure [ bar ] | Maximum input pressure [ bar ] | Viscosity [ mPas ] | Temperature range [ °C ] | Download |
|---|---|---|---|---|---|---|---|---|
| 3050 | 0.45 | 4000 | 1.8 2.8 4.4 | 7 30 | 60 90 | 0.5 ... 3000 0.5 ... 20,000 | -20 ... 70 -40 … 200 | CAD data CAD data CAD data |
| 4050 | 2.8 4.5 7.1 * | 3500 3000 | 9.8 15 21 | 7 30 | 60 90 | 0.5 ... 5000 0.5 ... 20,000 | -20 ... 70 -40 … 200 | CAD data CAD data CAD data |
* maximum possible application area with application-specific and constructive adjustments
Possible material combinations
| Casings & shafts | Gear wheels | Slide bearings | Seals |
|---|---|---|---|
| Titanium | PEEK mod. PEEK HT PTFE mod. PPS mod. | PEEK mod. PTFE mod. PPS mod. SSiC / Cr2O3 SSiC / Al2O3 | PTFE FKM FFKM EPDM |
